This light weight, flexible, non-metallic hose has a specially compounded rigid PVC reinforcement which is helically wound and inseparably fused to the soft inner walls.
By its unique construction, our ducting result in athin, very smooth wall being almost completely protected from the crushing.
Product Specification
| Size | Diameter | Bending Radius | Standard Lengths |
||
|---|---|---|---|---|---|
| mm | Inch | Id mm | Od mm | mm | Meter |
| 22 | 3/4 | 21 | 28.60 | 35 | 30 |
| 25 | 1 | 25.4 | 31.10 | 45 | 30 |
| 30 | 11/4 | 31.8 | 38.64 | 50 | 30 |
| 40 | 1 1/2 | 38 | 45.00 | 55 | 30 |
| 50 | 2 | 50.8 | 57.20 | 65 | 30 |
| 60 | 21/2 | 60.5 | 68.50 | 75 | 30 |
| 75 | 3 | 76.5 | 83.54 | 95 | 30 |
| 90 | 31/2 | 90.00 | 97.04 | 110 | 30 |
| 100 | 4 | 101.2 | 108.94 | 125 | 30 |
| 125 | 5 | 127 | 135.20 | 140 | 15 |
| 140 | 51/2 | 140 | 148.5 | 150 | 15 |
| 150 | 6 | 152.4 | 161.10 | 205 | 15 |
| 160 | 61/4 | 160 | 170 | 210 | 15 |
| 200 | 8 | 204 | 214.40 | 270 | 10 |
| 250 | 10 | 253.0 | 264.00 | 370 | 10 |
| 300 | 12 | 305.0 | 319.00 | 470 | 10 |
